Terex Jaques JW42 Jaw Crusher, 42" x 30" (1070mm x 760mm) Feed Opening, 75mm Minimum CSS, 18,000kgs

TEREX JAQUES JW42

2017 METSO LT220D Tracked Cone Crusher with onboard Screen
One Owner, full service history available
Efficiency and cost savings with LT220D cone crusher
Lokotrack® LT220D mobile crusher combines a cone crusher and a screen on the same chassis, which why it is often referred as Lokotrack® LT220D mobile crushing and screening plant. It is typically used as a secondary or tertiary crushing plant in a multistage crushing process to produce up to three calibrated end products.
POWERFUL COMBINATION OF CRUSHER AND SCREEN
Lokotrack® LT220D can be equipped with either the proven and powerful Nordberg® GP220 or HP200 cone crushing unit which are engineered for versatile aggregates production requirements. A large 8.4 m2 (10 yd2) screen provides high capacity as well as excellent screening efficiency.
Both crusher and screen run with a single CAT® C13 diesel engine. Maximum power is made available to the crusher by using hydraulic drive power transmission, resulting in reduced fuel consumption and running costs.
OPTIMUM CRUSHING RESULTS
The Metso IC process control system optimizes crushing results. It allows one-button start and stop, with built-in troubleshooting and a variety of parameter selections. All Lokotrack® mobile crushers in the same crushing process can be connected to the Metso IC system. In addition, the entire process can be conveniently monitored and controlled from the excavator's cab using the Metso Remote IC application for remote process control.
COMPACT AND TRANSPORTABLE
Lokotrack® LT220D is easy to move between the sites thanks to its compact design and weight. It can be set up in only minutes due to its hydraulically operated screen lifting and folding side conveyors.
SAFE AND EASY MAINTENANCE
Metso is investing heavily in its equipment safety and easy maintenance. In Lokotrack® LT220D, safe and easy daily operations are ensured with an extensive platform, and easy access to cone crusher maintenance points and for changing screening media.
Ideal for
Efficient secondary crushing and screening applications
Producing up to three end products using just LT220D and a primary crushing plant
Benefits
Crusher and screen combined
High-capacity ensured by powerful crusher and screen
Excellent energy efficiency
Quick to set up with hydraulic functions
Long-term investment with high resale value
Lokotrack® LT220D mobile crusher's technical specifications
MODEL
LOKOTRACK® LT220D
Crusher unit Nordberg® GP220 / Nordberg® HP200
Feed opening 210 / 185 mm (8 / 7)
Engine CAT®, 310 kW (415 hp)
Transport dimensions
Weight 46,000 kg (101,000 lbs)
Width 3,000 mm (9'10")
Height 3,500 mm (11'6")
Length 16,500 mm (54')

METSO LT220D

Changing work sites and new applications often create challenges for screening plants. The mobile screen for coarse elements MOBISCREEN MSS 802 EVO is ideally prepared for this. The large range of screen surfaces and the simple setting of screening parameters make it possible to adapt the MSS 802 EVO easily to new application conditions.
Mobile double-deck screening unit
H-DRIVE Diesel-hydraulic drive
Screen for coarse elements
Maximum feed size 500 mm
Highlights
Flexibility, ease of use and ergonomics: the high-performance MOBISCREEN MSS 802 EVO mobile coarse screening plants are convincing in different areas of application and differ primarily in their size.

2022 KLEEMANN MSS802 EVO

Price reduced to $395,000 + gst
ARAN MODUMIX II RCC PUGMILL PLANT - Modular Pugmill Plant capable of continuously mixing 400m3 per hour of RCC (Roller Compacted Concrete). Duo Feed Bin Arrangement,  Dual Overhead Mounted Cement Silos, Aran 4m Long Twin Shaft Pugmill, 25m Discharge Conveyor, Overhead Discharge Gob Hopper. Ground mounted Water Tanks. Generator powered (Generator not included). Plant was fully operational prior to decommissioning.
Offered on an "As Is Where Is" basis, Buyer to remove.

CUSTOM ARAN MODUMIX II RCC PUGMILL PLANT

Powered by 4-71 GM Engine, 8/6 Austral Pump, Rose Bud cutter head, 6m ladder, spuds, Good Condition

DREDGE CUTTER HEAD & SUCTION MOUTH DREDGE 8/6

Kemco 48" x 40" Single Toggle Jaw Crusher, mounted on heavy duty skid with 185kw motor drive and flywheel guards.
CSS 100-250mm
Capacity 200-500tph
For transport, it is one module measuring 7,500mm Long x 3,300mm wide x 4,000mm high (including guards). Weight is estimated at 60,000-65,000kg. Crusher 42,000kg.

KEMCO S7N 48X40 SINGLE TOGGLE

Track Mounted Cobra 1000 Horizontal Shaft Impactor, 3 Bar Rotor, Caterpillar C7 300HP. 80-120tph, new wear parts. Will closed circuit with Finlay 683 or similar screener

COBRA 1000

Pegson Telsmith Hadfields 3ft Gyrospere Cone Crusher mounted on skidbase complete with new drive motor, electrics and hydraulic lubrication.

PEGSON 36"

Cummins 1000KVA, KTA 2300, Semi Acoustic Enclosure, approx 5,000 total engine hours, 1,900hrs since new Alternator

CUMMINS 1000KVA

57m x 900mm Truss Section Conveyor, single sided walkway, GTU, complete with support trestles, dismantled and stored.

CUSTOM BUILT 57M X 900MM

AVAILABLE FOR HIRE or PURCHASE

REFURBISHED 2006 STRIKER CR300 fitted with METSO HP300 Cone Crusher, Caterpillar C13 Engine, HTPO 700HP Clutch,
- Metso HP300 - Fully Refurbished at 11,700hrs (At 160hrs on new meter) and is current hours)
- Caterpillar C13 engine. New Crate Engine fitted at 6750hrs. (Has done 4,950hrs)
- PT Tech HPTO14VG drive coupling fitted new 10500 hrs. Rated to 765HP, 80% duty cycle. (Has done 1,200hrs)
- New Track chains fitter
- 90% Hydraulic hoses replaced
- New PLC Control System fitted
- Completely Sandblasted and Painted

2006 METSO HP300

2008 FINTEC 1080 Cone Crusher 11,200hrs
Sandvik CH430 Crushing Chamber
5m3 Hopper Capacity
CSS Range: 7.5mm 35mm
CSS Adjustment: Hydraulic
Capacity: Up to 220 MTPH
Max Feed Size: 190mm
Operating Weight: 38,000KG
Operating weight: 38t Transport length: 14.3m Transport width: 3.0m Transport height: 3.4m Plant type: RM Crusher type: BB

2008 FINTEC 1080 CONE CRUSHER
